| Power | 0.25 HP to 20 HP (0.18 kW to 15 kW) |
| Frame Size | 63 to 180 L |
| Polarity | 2, 4, 6, 8 |
| Mounting | B3, B5, B14 & Combinations |
| Voltage | 415 V ± 10% or as required |
| Duty Cycle | S1 to S4 |
| Frequency | 50 Hz ± 5% or as required |
| Protection | IP 55 or other on request |
| Ambient | 40ºC |
| Construction | Aluminium Body & Cast Iron Body |
| Enclosure | TEFC |
| Insulation Class | Class F |
